BSV N-BSsalt-10 Salt Water Chlorinator

Login to view prices

SKU: SE-SC-BSV-BSSALT-100
Availability: In Stock
Share:

Compact salt water chlorinator

in IP65 box with digital display for private pools or pools up to 100m3 (see below for recommended models based on pool volume).
Chlorine production range: option for 10g/h, or 20g/h, or 25g/h, or 35g/h

Features:

  • Lower electrical consumption
  • Lower weight
  • (IP65) waterproof index
  • Lower operating temperature
  • More compact, easily adaptable to any installation
  • Switch mode power supply improves importantly the unit performance
  • Longer durability of the electrolysis cell
  • Internal microprocessor control, that determines the device operating hours</li

All BSV Salt Chlorinators have a high efficiency Switch Mode Power Supply* built in.

Table of Comparison of Power Supply
SWITCH MODE POWER SUPPLY* Conventional Power (Electric Transformer)
Performance 80-90% 30-50%
Cooling System Heat Convection Fan
Ingress Protection (IP) IP65 IP24
Sea Water Compatibility Yes Requires modification
230V / 110V Compatibility Yes Requires modification
Current Direct Alternating

Don’t see the model or type you are looking for? Contact us!

Product Details

Model N-Bssalt-10 N-Bssalt-15 N-Bssalt-20 N-Bssalt-25 N-Bssalt-35
Power Supply 230VAC, 50Hz
Max Cell Current 10A 15A 20A 25A 35A
Gr/Hour Production 10g/h 15g/h 20g/h 25g/h 35g/h
Max Power 75W 112.5W 150W 187.5W 263W
Max Cell Voltage 7.5Vcc
Salt Required 4g/l
Language Selection
Manual Regulation of Chlorine
Automatic Regulation of Chlorine
Indicator of ORP Values
Indicator of pH Values
Automatic Indicator of Lack of Salt
Automatic Indicator of Salt Excess
Self-Cleaning
Salt Level Indicator
Cell Life Indicator

All machines are equipped with automatic alarms that will sound for: Lack of Water Flow, Gas Accumulation in Cell, Overload, Short Circuit, and Overheating.

To enable the machine to better sense lack of flow, the Flow Sensor Kit can be equipped.

Recommended salt chlorinator production levels for the following private pool sizes:

Swimming Pool Volume (m3)
Filtration Hours (hour) 25 50 75 100 125 150 175 200
4 15 g/h 25 g/h
6 10 g/h 20 g/h 25 g/h 35 g/h
8 10 g/h 15 g/h 20 g/h 25 g/h 35 g/h 35 g/h
10 15 g/h 20 g/h 25 g/h 35 g/h 35 g/h
12 20 g/h 25 g/h 25 g/h 35 g/h 25 g/h

NOTE: When the pool water temperature exceeds 28 °C regularly, select the production immediately higher than indicated by the table.

When sized according to the table above, the BSV machine will produce a minimum of 2ppm of CL2 per day. Based on BSV’s experience in the field of disinfection of pool water, this level will be sufficient to keep the pool water disinfected and in perfect condition for a comfortable experience by users. Note that local governmental regulations still apply.

BSV_Catalog2019-2020

Select Type

10g/h Salt Water Chlorinator + cell, 25g/h Salt Water Chlorinator + cell

Brand

BSV
